FCO 711

Standards

EN 14700 T Z Fe13
TS EN 14700 T Z Fe13

Properties and Applications

Open arc flux cored wire for hardfacing of parts, exposed to high abrasion by soil, sand, rock and minerals in quarry, mining , agricultural and earthmoving equipments. Specially formulated as Cr-free electrode which eliminates generation of harmful Chromium (VI) fume during welding. Hard and high wear-resistant overlay has low impact resistance so, it is recommended to apply on the parts, where impact does not exist. Apply maximum of 2 layers to prevent spallling.

Typical Applications: Hardfacing of mixer blades and shafts, impellers, buckets, shovels, agriculturall equipments, augers soil and cement industry.
Fco 711 Sert Dolgu

Wear Resistance Types


Abrasion

Adhesion

Impact

Temperature

Corrosion
Low
Medium
High
Very High

Application Information

Welding Positions :
Fco 711 Kaynak Pozisyonu Fco 711 Kaynak Pozisyonu

Polarity:

Fco 711 Kutuplama DC(+)

Welding Parameters & Efficiency :

Diameter (mm)Deposition Rate(kg/h)Efficiency(%)
1.604.3895

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
38215GJAM21.6015.0115.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
