FCW 142M

Standards

AWS/ASME SFA - 5.28 E80C-Ni1 H4
EN ISO 17632 - A T 46 5 1Ni M M21 3 H5
TS EN ISO 17632 - A T 46 5 1Ni M M21 3 H5

Properties and Applications

Metal cored welding wire with 1%Ni. Has high toughness and notch impact values. at -50°C. Provides very good welding properties in the short-arc and spray arc range. Almost spatter-free when welding in the spray-arc range with mixed gas. Due to it's easily controlable weld pool in the short-arc range, it is well-suited for root pass and gap bridging purposes. Good arc striking, even with cold wire tip, thus being suitable for robotic applications. Provides high deposition rate with high welding speeds. Good side wall fusion, finely rippled welds without undercut. Weld metal has a little silicate formation on surface which makes multi-pass welding easier.
Fcw 142M Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNi
Weld Deposit0.060.401.150.90

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2151058025-50°C → 85

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 -M21 (Ar + %20 CO2) .

Application Information

Welding Positions :
Fcw 142M Kaynak Pozisyonu Fcw 142M Kaynak Pozisyonu

Polarity:

Fcw 142M Kutuplama DC(+)

Protection Gas:

M21

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
32009EJAM21.2015.0115.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
