MG 192

Datasheet

Standards

AWS/ASME SFA - 5.28	ER120S-G
EN ISO 16834 - A	G 89 6 M21 Mn4Ni2CrMo
TS EN ISO 16834 - A	G 89 6 M21 Mn4Ni2CrMo

Materials

EN	ASTM
S690Q-S890Q
S690QL-S890QL
S690QLN-S890QLN
*S960QL
*S1100QL
*S1300QL
	HY80
	HY100
	Q1(N)
	Q2(N)

Properties and Applications

Low alloyed wire electrode for GMA (MIG/MAG) welding of fine grained and high strength steels with yield strength of up to 960 N/mm2. Weld metal exhibits good toughness properties down to -60°C. Especially used in earthmoving, mining equipments, trucks, mobile cranes, concrete pumps crane,lift and oilfield equipments productions.

Mg 192 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of Analysis

C

Si

Mn

Cr

Ni

Mo

Welding Wire

0.09

0.80

1.80

0.30

2.20

0.55

Typical Mechanical Values of Weld Metal(%)

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

M21

980

1050

15

-60°C → 50

* Chemical compositon and mechanical properties are valid when using shielding gas .

Application Information

Welding Positions :

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Mg 192 Kaynak Pozisyonu

Polarity:

Mg 192 Kutuplama

DC(+)

Protection Gas:

M21

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
22025DJAM2	1.00	15.0	1	15.7	Wire Basket Spool (K300MS)
22025EJAM2	1.20	15.0	1	15.7	Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
