MI 309LSI

Standards

AWS/ASME SFA - 5.9 ER309LSi
EN ISO 14343 - A G 23 12 LSi
TS EN ISO 14343 - A G 23 12 LSi
DIN M. No. 1.4332

Materials

EN Material ASTM
X5CrNi18-10 1.4301 304
X2CrNi19-11 1.4306 304L
X6CrNiTi18-10 1.4541 321
X5CrNiMo17-12-2 1.4401 316
X2CrNiMo18-14-3 1.4435 316L
X6CrNiMoTi17-12-2 1.4571 316 Ti
1.4583 318

Properties and Applications

Austenitic-ferritic wire electrode for GMA (MIG/MAG) welding of dissimilar joints of stainless steels to unallyoed or low-alloyed steels, subjected to operating temperatures up to 300°C. Suitable to use also as buffer layer on carbon steel before welding with 308 and 308L to reach 304 and 304L layer. Low carbon content increases resistance to intergranular corrosion.
Mi 309Lsi Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNi
Welding Wire0.010.701.9023.5013.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM134606003820°C → 100

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M13 (Ar+%0,5-3 O2) .

Application Information

Welding Positions :
Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu Mi 309Lsi Kaynak Pozisyonu

Polarity:

Mi 309Lsi Kutuplama DC(+)

Protection Gas:

M13 M12 M14 I1

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
23003BAKM20.801.01415.7Plastic Spool (D100)
23003BBAM20.805.015.3Plastic Spool (D200)
23003BJAM20.8015.0115.7Wire Basket Spool (K300MS)
23003DBAM21.005.015.3Plastic Spool (D200)
23003DJAM21.0015.0115.7Wire Basket Spool (K300MS)
23003EJAM21.2015.0115.7Wire Basket Spool (K300MS)
23003GJAM21.6015.0115.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
