SI 309L

Datasheet

Standards

AWS/ASME SFA - 5.9	ER309L
EN ISO 14343 - A	S 23 12 L
TS EN ISO 14343 - A	S 23 12 L
DIN M. No.	1.4332

Properties and Applications

Austenitic-ferritic wire electrode for submerged arc welding of stainless steels to unalloyed or low-alloyed steels, subjected to operating temperatures up to 300°C. Used in combination with SIF 501 and SIF 502 submerged arc welding fluxes. Low carbon content increases resistance to intergranular corrosion. Suitable to use also for buffer layer on carbon steel before welding with 308 and 308L to reach 304 and 304L surface layer.

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn	Cr	Ni
Welding Wire	0.02	0.40	1.80	24.50	13.50

Type of Analysis

Welding Wire

0.02

0.40

1.80

24.50

13.50

Typical Chemical Values of Weld Metal

Welding Flux	Type of Analysis	C	Si	Mn	Cr	Ni
SIF 502	Weld Deposit	0.02	0.75	1.45	20.50	11.50
SIF 501	Weld Deposit	0.02	0.40	1.75	20.00	11.00

Typical Mechanical Values of Weld Metal(%)

Test Condition	Welding Flux	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	SIF 502	410	560	34	20°C → 70	-60°C → 40	-196°C → 30
As welded	SIF 501	410	560	35	20°C → 80	-60°C → 60	-196°C → 40

Test Condition

Welding Flux

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

SIF 502

410

560

20°C → 70

-60°C → 40

-196°C → 30

As welded

SIF 501

410

560

20°C → 80

-60°C → 60

-196°C → 40

Application Information

Welding Positions :

Polarity:

DC(+)

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
43002IXAM2	2.40	25.0	1	25.9	Wire Basket Spool (K435)
43002LXAM2	3.20	25.0	1	25.9	Wire Basket Spool (K435)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
