TCU AL8

Standards

AWS/ASME SFA - 5.7 ERCuAl-A1
EN ISO 24373 S Cu 6100 (CuAl7)
TS EN ISO 24373 S Cu 6100 (CuAl7)
DIN M. No. 2.0921

Kullanıldığı Ana Malzemeler

DIN Material ASTM
Cu Al 5 2.0916 C60600
Cu Al 8 2.092 C61000
Cu Zn 37 Al 2.0510
G Cu Al 9 2.0928

Özellikleri ve Uygulama Alanları

Aluminium bronze welding rod for GTA (TIG) welding of aluminium bronzes, high strength brass and surfacing of steel, gray cast iron used in machine building and in the chemical industry, as well as in shipbuilding. Alloy showing resistance to corrosion and erosion to sea water, with a very good metal to metal sliding properties. Suitable for also welding joints on corrosion resistant aluminium bronze or high strength brass pipes. Joining copper tubing to steel. Surface build-up on ship propellers, skid rails, bearing surfaces, bearings, valves, slide gates, fittings.
Tcu Al8 Sert Dolgu

Kaynak Telinin Tipik Kimyasal Özellikleri

Type of AnalysisMnNiAlCu
Welding Wire0.200.208.0091.50

Kaynak Metalinin Tipik Mekanik Özellikleri(%)

Test ŞekliProtection GasAkma Dayanımı (N/mm²)Çekme Dayanımı (N/mm²)Elongation A5 (%)Hardness (HB)
Kaynak SonrasıI120043040100

* Kimyasal kompozisyon ve mekanik özellikler EN ISO 14175 - I1 (%100 Ar) koruyucu gazının kullanılması durumunda geçerlidir.

Application Information

Kullanılabilecek Kaynak Pozisyonları :
Tcu Al8 Kaynak Pozisyonu Tcu Al8 Kaynak Pozisyonu Tcu Al8 Kaynak Pozisyonu Tcu Al8 Kaynak Pozisyonu Tcu Al8 Kaynak Pozisyonu Tcu Al8 Kaynak Pozisyonu

Polarity:

Tcu Al8 Kutuplama DC(-)

Protection Gas:

I1

Welding Parameters & Efficiency :

Packaging Information

Ürün KoduÇap X Uzunluk (mm)Kutu Ağırlığı (kg)Number Of Boxes Per PackageKoli AğırlığıPackaging Type
25102IBKM22.40x10005.015.2Cardboard Tube
25102LBKM23.20x10005.015.2Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
