TG 2

Datasheet

Standards

AWS/ASME SFA - 5.18	ER70S-6
EN ISO 636 - A	W 42 2 3Si1
TS EN ISO 636 - A	W 42 2 3Si1
DIN M. No.	1.5125

Approvals & Certificates

TUV

CWB

DNV

Materials

EN	DIN
S185 - P355T1	St 33.0 - St 52.0
S235J2 - S355J0	St 37.3 - St 52.3
P235TR2 - P2355T2	St 37.4 - St 52.4
P235G1TH - P255G1TH	St 35.8 - St 45.8
E295	St 50.2
P235GH - P265GH	H I - H II
P295GH, P355GH	17Mn4, 19Mn5
L210 - L360NB	StE 210.7 - StE 360.7
GE 200, GE 240, GE 260	GS 38, GS 45, GS 52
S255N - S380N	StE 255 - StE 380
	A, B, D, E
	X42, X46

Properties and Applications

GTA (TIG) welding rod for unalloyed steels, fine grained steels and pipes. Particularly used in root and cap passes in chemical, petrochemical, water, natural gas pipes joints safely. Suitable also welding of thin metal plates, tanks, boilers and repair welds of them. Thin and homogeneous copper coating increase resistance to rusting.

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn
Welding Wire	0.06	0.80	1.45

Type of Analysis

Welding Wire

0.06

0.80

1.45

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	I1	480	560	28	-20°C → 95	-30°C → 80

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

480

560

-20°C → 95

-30°C → 80

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Polarity:

DC(-)

Protection Gas:

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter X Length (mm)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
21102GBKM2	1.60x1000	5.0	4	21.4	Cardboard Tube
21102GBLM2	1.60x1000	5.0	4	21.4	Cardboard Tube
21102GGKM2	1.60x1000	5.0	4	21.4	Plastic Box
21102HBKM2	2.00x1000	5.0	4	21.4	Cardboard Tube
21102HGKM2	2.00x1000	5.0	4	21.4	Plastic Box
21102IBKM2	2.40x1000	5.0	4	21.4	Cardboard Tube
21102IGKM2	2.40x1000	5.0	4	21.4	Plastic Box
21102LBKM2	3.20x1000	5.0	4	21.4	Cardboard Tube
21102LGKM2	3.20x1000	5.0	4	21.4	PLASTIK
21102MBKM2	4.00x1000	5.0	4	21.4	Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
