TG 295

Standards

AWS/ASME SFA - 5.28 ER90S-B9
EN ISO 21952 - A W CrMo91
TS EN ISO 21952 - A W CrMo91
DIN M. No. 1.4903

Approvals & Certificates

Properties and Applications

High-alloyed, GTA (TIG) welding rod for creep, oxidation and corrosion resistant Cr-Mo-V-Nb alloyed steels, subjected to operating temperatures in 650°C. Suitable for welding P91 and T91 steels used in steam generators, turbine rotors, boiler, piping in refineries, chemical industry and thermal power generation industry. Due to it's high steam and hot hydrogen corrosion resistance, particularly used in root and cap passes of in steam generators, boilers, pressure vessels and piping in refineries, where high X-ray quality is required. Observe directions of pre- and post-weld heat treatment of base metal.
Tg 295 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNiMoVNbCu
Welding Wire0.100.300,509.200.650.950.200.050.02

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
Isıl İşlem Sonrası (780°C 2 Saat)I16507501920°C → 100

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :
Tg 295 Kaynak Pozisyonu Tg 295 Kaynak Pozisyonu Tg 295 Kaynak Pozisyonu Tg 295 Kaynak Pozisyonu Tg 295 Kaynak Pozisyonu Tg 295 Kaynak Pozisyonu

Polarity:

Tg 295 Kutuplama DC(-)

Protection Gas:

I1

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter X Length (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
22108HBKM22.00x10005.0421.4Cardboard Tube
22108IBKM22.40x10005.0421.4Cardboard Tube
22108LBKM23.20x10005.0421.4Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
