EI 309LRS

Standards

AWS/ASME SFA - 5.4 E309L-17
EN ISO 3581 - A E 23 12 L R 12
TS EN ISO 3581 - A E 23 12 L R 12
DIN M. No. 1.4332

Properties and Applications

Rutile type electrode for joining dissimilar steels (austenitic steels to ferritic steels) and for austenitic claddings on ferritic steels. Weld metal consists of austenite with approx. 15% delta-ferrite. Claddings on unalloyed and low alloy steels are already corrosion resistant in the first layer. Higher operating temperature for joints between dissimilar steels is 300°C. Fine metal droplet transfer, good fusion of joint faces, finely ripped flat and smooth bead surface, especially in fillet welds. Easy slag removal of slag.
Ei 309Lrs Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrNi
Weld Deposit0.030.901.1023.0012.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded4505704020°C → 60

Application Information

Welding Positions :
Ei 309Lrs Kaynak Pozisyonu Ei 309Lrs Kaynak Pozisyonu Ei 309Lrs Kaynak Pozisyonu Ei 309Lrs Kaynak Pozisyonu Ei 309Lrs Kaynak Pozisyonu Ei 309Lrs Kaynak Pozisyonu

Polarity:

Ei 309Lrs Kutuplama DC(+)
Ei 309Lrs Kutuplama AC

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
2.50x30050-80
3.25x35080-120
4.00x350100-165

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
13030GJEM22.50x300961.81018.2VAC Box
13030NJEM23.25x350542.01018.6VAC Box
13030QJEM24.00x350372.01021.0VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
