EIS 410

Standards

AWS/ASME SFA - 5.4 E410-15
EN ISO 3581 - A E (13) B 42
TS EN ISO 3581 - A E (13) B 42
DIN M. No. ~1.4009

Approvals & Certificates

Materials

EN Material ASTM
X6Cr13 1.4000 410S
X6CrAl13 1.4002 405
X12Cr13 1.4006 410
GX12Cr12 1.4011
GX7CrNiMo12-1 1.4008
X20Cr13 1.4021 420
X15Cr13 1.4024
G-X20Cr14 1.4027

Properties and Applications

Basic type stainless steel electrode with high recovery, which is used for welding of approx. 13% Cr containing stainless and heat resistant chromium steels or cast steels. Deposits martensitic stainless steel weld metal. Also suitable for corrosion and abrasion resistant surfacing of contact surfaces of gas, water and steam fan, fan blades and fittings subjected to operating temperatures up to 450°C. Weld metal is non-scaling up to 850°C. Use with DCEP. Depending on type of base metal and wall thickness, preheating and interpass temperatures from 100 to 400°C and tempering at 650 to 750°C are advisable.
Eis 410 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrNi
Weld Deposit0.060.450.8012.000,50

Typical Mechanical Values of Weld Metal(%)

Test ConditionTensile Strength (N/mm²)Elongation A5 (%)Hardness (HB)Charpy V-Notch Properties (J)
Isıl İşlem Sonrası (740°C 1 Saat)7502237520°C → 50

Application Information

Welding Positions :
Eis 410 Kaynak Pozisyonu Eis 410 Kaynak Pozisyonu Eis 410 Kaynak Pozisyonu Eis 410 Kaynak Pozisyonu Eis 410 Kaynak Pozisyonu Eis 410 Kaynak Pozisyonu

Polarity:

Eis 410 Kutuplama DC(+)

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.50x35060-900,68611125
3.25x35080-1400,68431,23125
4.00x350125-1800,69281,75125

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
13024HJEM22.50x350892.01021.0VAC Box
13024HKEM22.50x3502245.0315.4VAC Box
13024NJEM23.25x350602.0100.0VAC Box
13024NKEM23.25x3501495.0315.4VAC Box
13024QKEM24.00x350965.0315.4VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
