EM 171

Standards

AWS/ASME SFA - 5.5 E8018-C1 H4
EN ISO 2560 - A E 46 6 2Ni B 42 H5
TS EN ISO 2560 - A E 46 6 2Ni B 42 H5

Approvals & Certificates

Kullanıldığı Ana Malzemeler

EN DIN ASTM
S255NL - S420NL TStE 255 - TStE 420
A537 Class I
A537 Class II
S255N - S420N StE 255 - StE 420
12Ni14 10 Ni 14
S225NL TT St 35N

Özellikleri ve Uygulama Alanları

Heavy coated basic type electrode for welding fine grained structural steels and especially cryogenic steels, subjected to low service temperatures up to -60°C. Electrode produces tough and crack-free welded joints. Weld deposit is of extremely high metallurgical purity and very low hydrogen content. Owing to high crack resistance under difficult conditions such as dynamic loads, impact, vibration and low service temperatures, it is suitable for use in welding of storage tanks and piping. Suitable for use in root passes and joints in pipes and equipments of cold storage rooms with service temperatures down to -60°C. Electrode features a stable and concentrated arc. Especially 2,50 mm and 3,25 mm diameters are well-suited for positional welding. Welds are X-ray quality.
Em 171 Sert Dolgu

Kaynak Metalinin Tipik Kimyasal Özellikleri

Type of AnalysisCSiMnNiCu
Weld Deposit0.050.301.002.400.08

Kaynak Metalinin Tipik Mekanik Özellikleri(%)

Test ŞekliAkma Dayanımı (N/mm²)Çekme Dayanımı (N/mm²)Elongation A5 (%)Çentik Darbe Dayanımı ISO-V (J)
Kaynak Sonrası49058027-60°C → 100
Isıl İşlem Sonrası (605°C 1 Saat)47055029-60°C → 120

Application Information

Kullanılabilecek Kaynak Pozisyonları :
Em 171 Kaynak Pozisyonu Em 171 Kaynak Pozisyonu Em 171 Kaynak Pozisyonu Em 171 Kaynak Pozisyonu Em 171 Kaynak Pozisyonu Em 171 Kaynak Pozisyonu

Polarity:

Em 171 Kutuplama DC(+)

Welding Parameters & Efficiency :

Çap x Uzunluk (mm)Akım (A)
2.50x35060-90
3.25x35090-140
4.00x450130-180
5.00x450190-230
6.00x450260-340

Packaging Information

Ürün KoduÇap X Uzunluk (mm)Pieces per Box (~)Kutu Ağırlığı (kg)Number Of Boxes Per PackageKoli AğırlığıPackaging Type
12007HREM22.50x3502024.5313.9Cardboard Box
12007NKEM23.25x350732.5615.5VAC Box
12007NREM23.25x3501314.5313.9Cardboard Box
12007SSEM24.00x450966.5319.9Cardboard Box
12007VSEM25.00x450646.5319.9Cardboard Box
12007XSEM26.00x450466.5319.9Cardboard Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
>It has to be dried at 350°C for 2 hours.
