ENI 404 (Mo)

Standards

AWS/ASME SFA - 5.15 ENiCu-B
EN ISO 1071 E C NiCu-B 3
TS EN ISO 1071 E C NiCu-B 3

Properties and Applications

Electrode having a nickel-copper core wire for welding cast iron with preheating. Iron admixture from base metal should be kept low. Well-suited to welding cast iron with lamellar graphite, white, and black heart malleable cast iron, nodular cast iron. Weld metal closely matches colour of base metal. Thus electrode is preferably used for making filler and cover passes or for filling-up shrinkage cavities. Provides easy arc striking and restriking and stable arc. Weld metal is machinable. Weld short beads, about 30 to 50 mm long. In order to reduce weld residual stresses, hammer-peen welds slightly before cooling.
Eni 404 (Mo) Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiCuFe
Weld Deposit0,500.200.8064.0031.003.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionHardness (HB)
As welded160

Application Information

Welding Positions :
Eni 404 (Mo) Kaynak Pozisyonu Eni 404 (Mo) Kaynak Pozisyonu Eni 404 (Mo) Kaynak Pozisyonu Eni 404 (Mo) Kaynak Pozisyonu Eni 404 (Mo) Kaynak Pozisyonu Eni 404 (Mo) Kaynak Pozisyonu

Polarity:

Eni 404 (Mo) Kutuplama DC(+)
Eni 404 (Mo) Kutuplama AC

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.50x30050-700,63960,56102
3.25x30090-1100,65560,96104
3.25x35090-110
4.00x400110-1400,68261,31103

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
16051GJEM22.50x3001041.81018.5VAC Box
16051MJEM23.25x300661.81018.2VAC Box
16051NJEM23.25x350572.0100.0VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
> It has to be dried at 150°C for 1 hour.
