ENI 412

Standards

AWS/ASME SFA - 5.15 ENi-CI
EN ISO 1071 E C Ni-CI 3
TS EN ISO 1071 E C Ni-CI 3

Materials

DIN
GG 10 - GG 35

Properties and Applications

Electrode having a nickel core wire, for welding on grey cast iron with and without preheating. Suitable for welding joints as well as for surfacing of worn cast iron parts. Suitable to use in repair of machine frames, machine housings, machine parts and bearing blocks. The electrode has a very soft, regular fusion, and a quiet and steady arc. It is well suited for positional welding. Very little dilution with the parent metal takes place, resulting in good machinability of the transition area. Weld short beads, about 30 to 50 mm long. In order to reduce weld residual stresses, hammer-peen welds slightly before cooling. Preferably is used with DCEN but possible to use with also AC.
Eni 412 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiTiAlFe
Weld Deposit0.800.800.2097.000.350.100.75

Typical Mechanical Values of Weld Metal(%)

Test ConditionHardness (HB)
As welded175

Application Information

Welding Positions :
Eni 412 Kaynak Pozisyonu Eni 412 Kaynak Pozisyonu Eni 412 Kaynak Pozisyonu Eni 412 Kaynak Pozisyonu Eni 412 Kaynak Pozisyonu Eni 412 Kaynak Pozisyonu

Polarity:

Eni 412 Kutuplama DC(-)
Eni 412 Kutuplama AC

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)Weld Deposit(Kg)/1Kg Consumed ElectrodeNumber of Electrodes/1Kg Weld DepositWeld Metal Deposition Rate (Kg/h)Efficiency(%)
2.50x30050-700,74820,51112
3.25x30090-1100,69740,74108
3.25x35090-110
4.00x400110-1400,77240,78105

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
16002GJEM22.50x3001091.81019.0VAC Box
16002MJEM23.25x300651.81018.5VAC Box
16002NJEM23.25x350572.0100.0VAC Box
16002RJEM24.00x400422.3921.0VAC Box

Storage & Re-Drying Information

>It can be dried maximum 5 times.
> It has to be dried at 150°C for 1 hour.
