ESA 20

Standards

AWS/ASME SFA - 5.1 E6027
EN ISO 2560 - A E 38 2 RA 73
TS EN ISO 2560 - A E 38 2 RA 73

Properties and Applications

Acid-rutile coated, high efficiency electrode having a weld metal approx 165 %. Especially designed for welding fillets and narrow angle grooves. Produces complete root fusion and equal-leg fillet welds. Suitable for welding of galvanized, primer painted and slightly rusted components. Due to its low Silicon (Si) content, weld metal is also suited for subsequent galvanizing, enamaling and rubber cladding after welding. Provides very smooth welds without undercut. Slag is easily released, even from narrow angles. Welds are of X-ray quality.
Esa 20 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMn
Weld Deposit0.070.451.15

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded4505302420°C → 100-20°C → 60

Application Information

Welding Positions :
Esa 20 Kaynak Pozisyonu Esa 20 Kaynak Pozisyonu

Polarity:

Esa 20 Kutuplama DC(-)
Esa 20 Kutuplama AC

Welding Parameters & Efficiency :

Diameter x Length (mm)Current (A)
3.25x450100-145
4.00x450130-210
5.00x450250-280

Packaging Information

Product CodeDiameter X Length (mm)Pieces per Box (~)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
11130PSEM23.25x450976.5319.9Cardboard Box
11130SSEM24.00x450666.5319.9Cardboard Box
11130VSEM25.00x450436.5319.9Cardboard Box

Storage & Re-Drying Information

>Generally not required. If required, redry for 1 hour at 110°C.
