FCH 801

Standards

AWS/ASME SFA - 5.21 ERCCoCr-C
EN 14700 T Co3
TS EN 14700 T Co3
DIN 8555 MF 20-GF-55-CGTZ

Properties and Applications

Gas shielded, flux cored hardfacing wire which deposits Co-Cr-W alloy weld metal. Suitable to use in hardfacing of parts subjected to either the single or combined effect of heavy metal-to-metal wear or abrasion, high temperatures (ranging from 500°C to 900°C) and corrosive environments. Due to its very high toughness and shock resistance extends its use for service conditions involving mechanical impacts and thermal shocks. Pure argon (l1) shall be used as shielding gas.

Typical Applications: Hardfacing of plastic extrusion screws, tools to cut paper, cardboard floor coverings,roofing,wood.
Fch 801 Sert Dolgu

Wear Resistance Types


Abrasion

Adhesion

Impact

Temperature

Corrosion
Low
Medium
High
Very High

Typical Applications

Fch 801 Model Tipik Uygulamalar Fch 801 Model Tipik Uygulamalar Fch 801 Model Tipik Uygulamalar Fch 801 Model Tipik Uygulamalar

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnCrNiWCoFe
Weld Deposit2.501.000,5030.002.0011.0049.503.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasHardness (HRc)
As weldedM1355

* Chemical compositon and mechanical properties are valid when using shielding gas .

Application Information

Welding Positions :
Fch 801 Kaynak Pozisyonu Fch 801 Kaynak Pozisyonu

Polarity:

Fch 801 Kutuplama DC(+)

Protection Gas:

M13

Welding Parameters & Efficiency :

Diameter (mm)Deposition Rate(kg/h)Efficiency(%)
1.202.9195
1.603.6195

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
38040EJAM21.2016.0116.7Wire Basket Spool (K300MS)
38040GJAM21.6016.0116.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
