MCU AL8

Datasheet

Standards

AWS/ASME SFA - 5.7	ERCuAl-A1
EN ISO 24373	S Cu 6100 (CuAl7)
TS EN ISO 24373	S Cu 6100 (CuAl7)
DIN M. No.	2.0921

Materials

DIN	Material	ASTM
Cu Al 5	2.0916	C60600
Cu Al 8	2.0920	C61000

Properties and Applications

8% Aluminium alloyed copper wire electrode for GMA (MIG) welding of copper-aluminyum (Cu-Al) alloys (aluminium-bronzes). Also suitable for surfacing of parts subjected to metal to metal wear under high compressive stresses or in the presence of corrosive agents (acids, sea water).

Mcu Al8 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of Analysis

Mn

Ni

Al

Cu

Welding Wire

0.20

0.30

8.00

91.50

Typical Physical Analysis of the Weld Metal (%)

Density (gr/cm³)	Conductivity (Sm/mm²)
0.00	0.11-0.14

Typical Mechanical Values of Weld Metal(%)

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Hardness (HB)

As welded

I1

200

430

40

100

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Mcu Al8 Kaynak Pozisyonu

Mcu Al8 Kaynak Pozisyonu

Mcu Al8 Kaynak Pozisyonu

Mcu Al8 Kaynak Pozisyonu

Mcu Al8 Kaynak Pozisyonu

Mcu Al8 Kaynak Pozisyonu

Polarity:

Mcu Al8 Kutuplama

DC(+)

Protection Gas:

I3 I1 I2

Welding Parameters & Efficiency :

Packaging Information

Product Code	Diameter (mm)	Weight Of The Box (kg)	Boxes Per Package	Weight Of The Package	Packaging Type
25002DHAM2	1.00	15.0	1	15.8	Plastic Spool (D300)
25002EHAM2	1.20	15.0	1	15.8	Plastic Spool (D300)
25002GHAM2	1.60	15.0	1	15.8	Plastic Spool (D300)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
